Features/Application
Pre-sensitized emulsion, ready-to-use. No Diazo required.
High resolution emulsion for reproduction of detailed and fine images.
Wider exposure latitude.
Easy to build EOM by fewer coats.
Best suited for textile and flag printing with plastisol and water based inks.
Consistent emulsion profile over the mesh, lower Rz value.
Extended shelf life.
Specifications
Viscosity: Approx. 4000 mPa･s, 25℃
Solid Contents: Approx. 40%
Packaging Standards: 1kg, 5kgs, 20kgs.
Contact us for custom packaging.
Exposure Data
| Screen mesh, Color | E.O.M (μm) | 2Kw Metal Halide lamp |
| Polyester 120/cm (300/inch) w | 5μm | 45-55 sec. |
| 15μm | 80-90 sec. | |
| Polyester 100/cm (250/inch) w | 5μm | 55-65 sec. |
| 15μm | 95105 sec. |
※The above is for guideline purposes only, kindly to use a gray scale exposure calculator to identify optimal exposure time.
Instructions
Wash, degrease and dry screen mesh. Remove grease and foreign contaminants with MSP cleanser.
Coat emulsion slowly in order to prevent air bubbles.
Dry coated screen completely before exposure. Drying temperatures up to 40℃(104℉).
Avoid excessive temperature for drying screens.
Avoid excessive temperature for drying screens.
Remarks
Keep the emulsion in a cool and UV light safe area.
Recommended to filter remaining emulsion with screen mesh before pouring it back into the container to remove any dust, foreign substances and air bubbles.
